“An error occurred while making the requested connection” – Citrix Web Interface

/ / /

So I’m getting the dreaded “An error occurred while making the requested connection” while trying to launch some applications from our Citrix Web Interface.  It started happening suddenly but I’m tasked with figuring out why.  First thing I did was go to the Web Interface and check the event logs.  I found the following:


This wasn’t much help, but I was able to narrow down that this was happening on one set of our servers that are split across two DC’s.  One set of servers at BDC was fine, the other set of servers at ADC had a subset of servers that were not.  Doing a qfarm /load showed the problematic servers had no users on them at all, and no load evaluators were applied that would be causing our issue.

Logging into the server it was deteremined that it’s DNS was registered to the wrong NIC (it was a PVS server that was multi-homed) and even worse for some of the servers, the NIC IP address was an old address and the new address wasn’t even resolving!

For some reason it now appears our Windows 2008 servers are not registering their DNS on startup.  To resolve this issue for us we added a startup script with the simple command “ipconfig /registerdns” and within a few seconds the IP address is registered within DNS correctly and with the correct NIC.  We suspect that something is misconfigured at ADC as BDC does not have this issue nor does it need this tweak, but this is our work around until that is resolved.

Read More

Powershell script to compare Citrix Webinterface files

/ / /

I’ve created a powershell script that will compare Citrix Webinterface files then export them out to a csv file.


Read More

Import-Csv -header $variable

/ / /

I ran into an issue with Import-CSV where I was trying to pass a variable to the -header and it was failing pretty horribly, creating a single field instead of multiple fields.

I created a script to generate a CSV from Citrix WebInterface .conf files to compare the various web interfaces we have so that when we migrate users from the older interface to the newer interfaces we can properly communicate to them the changes they will experience.  In the course of developing this script I wanted to do a “dir *.conf” command and use that output as the header in the CSV.  Here is what I did originally:

This failed.  Our $header variable became a single header in the CSV.  The help for “Import-CSV” says the -header should have a string value.  I tried $header.ToString() but it didn’t work either.  I found you need to do the following:

This makes an array then adds the appropriate values to the $header variable and the import-csv now has multiple columns.


Read More

Utilizing MCLI.exe to comment the newest version of a vDisk on Citrix Provisioning Services (PVS)

/ / /

I’ve written this script to utilize MCLI.exe to add a comment to the newest version of a vDisk and have marked which fields correspond to what.



This script can now be added to the “PVS Automatic” update feature to automatically comment the latest vDisk when it is updated.

Read More

Troubleshooting Audio issues in Citrix XenApp

/ / /

We recently ran across an issue with XenApp 6.5 where we were publishing an application that required the “Beep” but it wasn’t working.  The following is the troubleshooting steps I did to enable audio to work on that application.

First we created a Citrix policy to enable audio.  This policy looked like so:

We filtered on a user security group to enable the client audio redirection and added that filter group to the application.  From the original appearance of things, this should have been sufficient to enable client redirection.  But it did not.  So I wanted to verify that the policy was actually applying to the user account.  To do that, you login to the system with a user account and check in Regedit for the value “AllowAudioRedirection”.  If it’s set to 0x1 then the Citrix group policy has evaluated that client redirection should be enabled for your session.

Unfortunately, I still did not have audio redirection working…

Citrix advises that you can use dbgview.exe to further troubleshoot the Citrix Receiver to assist.  I launched dbgview.exe and started the trace and launched the application from the Webinterface.

“00000043 0.60113800 [7752] CAMSetAudioSecurity: Wd_FindVdByName failed”

CAM is a virtual channel (Virtual Channel Priority for Audio) and we can see it’s failing.  I then used the Citrix ICA creator and launched the application using that.  The dbgview for that output looks like so:

00000013 0.44386363 [4496] CAMSetAudioSecurity: success

We can see that the audio virtual channel was able to successfully latch and I confirmed I had audio in the application.

From here the issue appeared to be when I launched the application from the webinterface or desktop shortcut.  I then compared the two ICA files, the one from the web interface and the one I created separately to see what was different.  The difference was glaringly obvious.  The working ICA file had “ClientAudio=On” and the broken one had “ClientAudio=Off”.

Curious, I launched AppCenter and clicked through the applications settings and saw the following:

“Enable legacy audio” was unchecked.  I checked it and then logged off and logged back on the web interface and when I downloaded the ICA file, “ClientAudio=On” and I had audio.  I then unchecked that setting and confirmed it manipulated the ICA file as with it unchecked the ICA file generated had “ClientAudio=Off”

Who knows why it’s called “legacy audio”.  May as well just call that option “Enable audio” as that would be more accurate.  The Citrix documents on this setting says the following:
To enable or disable audio for published applications

If you disable audio for a published application, audio is not available within the application under any condition. If you enable audio for an application, you can use policy settings and filters to further define under what conditions audio is available within the application.

  1. In the Delivery Services Console, select the published application for which you want to enable or disable audio, and select Action > Application properties.
  2. In the Application Properties dialog box, click Advanced > Client options. Select or clear the Enable legacy audio check box.

Emphasis is mine.

Anyways, and now we have our applications with working audio and everything seems to be good again 🙂

To summarize the enable audio for a XenApp application you must:
1) Enable “legacy” audio
2) Enable a Citrix policy to configure audio redirection
3) Done.

Read More

Example of Standard Post

/ / /

Lorem ipsum dolor sit amet, consectetur adipiscing elit. Nunc a commodo nunc. Suspendisse mollis faucibus elementum. Donec vulputate erat ut turpis dictum vestibulum. Phasellus sit amet dui ut nisl vestibulum volutpat eget sit amet tortor. Suspendisse mollis porttitor orci, varius aliquet justo hendrerit convallis. Vestibulum quis mauris purus.

Read More

Powershell script to manipulate “Register this connection’s addresses in DNS”

/ / /

We run a multihome NIC setup with our Citrix PVS servers and the “Provisioning” Network is a seperate VLAN that is only used by the PVS servers and goes no where.  Unfortunately, however, the “Provision” NIC can register itself in the DNS, causing devices outside of the Provisioning network (everyone) to resolve to the incorrect address.  To resolve this I ran this script across all my vDisks to remove the ability of the provision network to register itself as available in DNS.:

As you can see above, we have two NICs, “Provision” and “Production”.  We do not want “Provision” registerted so it gets the $false,$false set, whereas “Production” gets $true,$false.

Read More

How to enable “Adaptive Display” in XenApp 6.5

/ / /

Contrary to the documentation in the Group Policy settings for Citrix, XenApp requires the following settings configured for Adaptive Display to be enabled:

User settings
Minimum Image Quality
This setting specifies the minimum acceptable image quality for Adaptive Display. The less compression used, the higher the quality of images displayed. Choose from Ultra High, Very High, High, Normal, or Low compression.
By default, this is set to Normal.

Moving Image Compression
This setting specifies whether or not Adaptive Display is enabled. Adaptive Display automatically adjusts the image quality of videos and transitional slides in slide shows based on available bandwidth. With Adaptive Display enabled, users should see smooth-running presentations with no reduction in quality.
By default, this is set to Enabled.

Target Minimum Frame Rate
This setting specifies the minimum frame rate you want. The minimum is a target and is not guaranteed. Adaptive Display automatically adjusts to stay at or above this setting where possible.
By default, this is set to 10 frames per second.

Progressive Compression Level
Set to Disabled

Even though the GPO’s state these only apply to XenDesktop, they also apply to XenApp and can be confirmed if you publish HDX Monitor 3.0 on a XenApp server and monitor the ICA session, you can see the transient quality increasing or decreasing depending on your scenario.

Read More

SCVMM: Install VM components Failed

/ / /

I’m attempting to deploy a virtual machine from a template but I get this error: Install VM components: Failed.



SO…  Long story short; if you are encountering this error, I would suggest booting your VHD file in a VM and re-sysprep /generalize it.  If you’ve maxed out on sysprep’s I have a post earlier in my blog on how to get around the 3-times limit and rerun sysprep.  Alternatively, you can try what I did, but I can’t gaurantee your success and replace the BCD file in your Library VHD with a BCD you *know* has been sysprepp’ed and try redeploying it.

I’ve ensured that HTTP and HTTPS is not blocked (firewall is disabled) and the agent on my SCVMM machine is installed and running.  So this error message is somewhat useless.

So I took my two boxes, 2012-SCVMM (the SCVMM server) and S5000VXN-SERVER (the Hyper-V host) and procmon’ed them while it was attempting to “Install VM Components” to try and understand what it’s trying to do.

After reinitating the task, we can see that the vmmAgent.exe on the Hyper-V host accesses the file about 2 seconds after I submit the command to retry the job.

A few seconds after this, it appears to “CreateFile” in the WindowsTemp directory; but this is not actually correct.

What it is really doing is *mounting* the VHD into a folder in the WindowsTemp directory.  You can actually watch this in action if you view Disk Management on the Hyper-V host while you execute the task.

So now that we know it’s mounting the file as a volume this helps us narrow down on what Hyper-V is attempting to do…  And I suspect what it is attempting to do is “offline servicing” of the attached vdisk/vhd.

After attaching the vdisk the next thing it does it query the BCD file on the system.  Maybe it needs to be in a certain mode to operate?  I’m not sure…

Continuing on we can see that events are written to the Microsoft-Windows-FileShareShadowCopyProvider Operational.evtx, System.evtx, and Microsoft-Windows-Bits-CompactServer Operational.evtx event logs.  Examining each log at the time stamp showed the FileShareShadowCopyProvider and System log were just noticed of volume shadow copy starting, but the BITS event log was interesting.



It showed that it was doing something with the BCD file.  The Hyper-V host was *serving* it out.  I suspect it was serving it to the SCVMM.
Looking back at the SCVMM server we see that was executing some WinRM commands.  Sadly, we do not know what commands it was trying to send.

If I mount the vhd file and check out the BCD file I can see that it appears to be corrupted in that it doesn’t know what the proper boot device should be.


It’s not actually corrupted though; the reason why the devices are unknown is because bcdedit isn’t finding the disk signature of the volume I mounted.  But it has the disk signature because I can boot with it without issue.

Continuing on…

In order to try and find out what commands WSMAN was sending I enabled debugview on the SCVMM server:

I then reproduced the error by rerunning the Create Virtual Machine job.

DebugView gave me more information to narrow down what was happening.  It appears that the process is failing with:

Doing some googling on this took me to a Korean Microsoft page where the following was stated:

Thinking about it, I do not think my VHD was SysPrep’ed.  I find it interesting that sysprep appears to do something to the BCD file.  To find out what sysprep does to the BCD file I booted up my 2012 VHD into Windows and ran sysprep, generalize and shutdown.

And……….?  Lets go to DebugView:


Voila!  It appears much better than before.  It found the drive correctly and checked the BCD file and found it is the “Generalize” state.  The *actual* image I originally made was NOT sysprep’ed and all I did was replace the BCD file, but it allowed it to continue beyond and the machine actually completed the imaging process properly.  It joined the domain and whatever else the answer file was I gave it in SCVMM.

It appears I was correct in my earlier assumption about what SCVMM is doing.  It goes and grabs the BCD file and transfers it from the target machine to itself, “fixes it up” (not sure what it’s doing at this stage precisely), then sends it back for injection.  Certainly a bit of a complicated process with a fair bit that can go wrong, but shame on Microsoft for having such a poor error message.  I suspect it wouldn’t have required much effort to push out a real message; something to the effect of, “The BCD of this vDisk does not appear to have been through the sysprep /generalize process.  Please rerun sysprep against the image and try again”.

SO…  Long story short; if you are encountering this error, I would suggest booting your VHD file in a VM and re-sysprep /generalize it.  If you’ve maxed out on sysprep’s I have a post earlier in my blog on how to get around the 3-times limit and rerun sysprep.  Alternatively, you can try what I did, but I can’t gaurantee your success and replace the BCD file in your Library VHD with a BCD you *know* has been sysprepp’ed and try redeploying it.
